Pakistan’s Deluge: NASA Story Compares Satellite Images from August 4 and 28; and Links to Aga Khan University and Focus Humanitarian Donation Pages

Featured Image at top of post: The floods in Pakistan have turned plains into seas. The featured image shows the district of Qambar on August 4, 2022 (left) and on August 28 (right). The following piece has been adapted from the NASA website. To read the article on NASA that contains additional information and features, please click Devastating Floods in Pakistan – Ed.]

Story by SARA E. PRATT
NASA Earth Observatory Images by JOSHUA STEVENS

using Landsat data from the U.S. Geological Survey and VIIRS data from NASA EOSDIS LANCEGIBS/Worldview, and the Joint Polar Satellite System (JPSS).

Since mid-June 2022, Pakistan has been drenched by extreme monsoon rains that have led to the country’s worst flooding in a decade. According to Pakistan’s National Disaster Management Authority, the floods have affected more than 33 million people and destroyed or damaged more than 1 million houses. At least 1,100 people were killed by floodwaters that inundated tens of thousands of square kilometers of the country.

Satellite Image August 4, 2022

The Floods in Pakistan Satellite Images from NASA

Satellite Image August 28, 2022

The Floods in Pakistan Satellite Images from NASA

The false-color images above were acquired by the Operational Land Imagers aboard the Landsat 8 and Landsat 9 satellites on August 4 and 28, respectively. The images combine shortwave infrared, near infrared, and red light (bands 6-5-4) to better distinguish flood waters (deep blue) beyond their natural channels.

The worst flooding occurred along the Indus River in the provinces of Punjab, Khyber Pakhtunkhwa, Balochistan, and Sindh. The provinces of Balochistan and Sindh have so far this year received five to six times their 30-year average rainfall. Most of that arrived in summer monsoon rains.

Across the country, about 150 bridges and 3,500 kilometers (2,200 miles) of roads have been destroyed, according to ReliefWeb. More than 700,000 livestock and 2 million acres of crops and orchards have also been lost.

Satellite Image August 31, 2022

The Floods in Pakistan Satellite Images from NASA

The image above (the white rectangle denotes the area shown in the Landsat overview in the previous images), acquired by the Visible Infrared Imaging Radiometer Suite (VIIRS) on the NOAA-20 satellite on August 31, 2022, shows the extent of flooding in the region. The image uses a combination of near-infrared and visible light to make it easier to see where rivers are out of their banks and spread across floodplains.

The immense volume of rain- and meltwater inundated the dams, reservoirs, canals, and channels of the country’s large and highly developed irrigation system. On August 31, the Indus River System Authority authorized some releases from dams because the water flowing in threatened to exceed the capacity of several reservoirs.

In the southern reaches of the Indus watershed, the deluge has turned plains into seas. The following two detailed images show the districts of Qambar and Shikarpur in Sindh province, which from July 1 to August 31 received 500 percent more rainfall than average.

Qambar and Shikarpur Districts on August 4 and August 28

The Floods in Pakistan Satellite Images from NASA
Qambar on August 4, 2022 (left) and on August 28 (right). Also shown as feature image at top of this post
The Floods in Pakistan Satellite Images from NASA
Shikarpur on August 4, 2022 (left) and on August 28 (right).

The effect of the monsoon rains has been compounded by the continued melting of Pakistan’s 7,000 glaciers. The country holds the most glacial ice found outside the polar regions. Climate warming and recent heat waves have precipitated several glacial-outburst floods. In the rugged northern part of the country, the combined rain and meltwater has turned slopes into hill torrents.

On August 30, the Pakistani government declared a national emergency and, with the United Nations Office for the Coordination of Humanitarian Affairs, called for international aid for humanitarian relief efforts.

Pakistan last faced such dramatic and widespread flooding in 2010.

Date posted: September 2, 2022.
Last updated: September 2, 2022 (6 AM EDT, see correction note below)

Correction: The title in the original version of the post suggested that all the images shown above were taken by NASA satellites. As is very clear in the story, the images are from more than one source, and the title has been revised accordingly. The editor apologizes for the oversight.

___________________

CONTRIBUTORS
(profiles and profile photos from NASA website)

Sara Pratt NASA Pakistan Floods Story
Sara Pratt

Sara Pratt has been a science writer for the NASA Earth Observatory since 2021. She is a former senior editor of EARTH Magazine, and her work has appeared in Eos, Oceanus, NOVA, and Discover. She also has editorial experience in science educational publishing. Sara holds a bachelor’s degree in geology and environmental studies from Penn and dual master’s degrees in earth & environmental science journalism from Columbia. She enjoys writing about any aspect of earth science but is most interested in coastal and marine geology, oceanography, and climate science.

Sara lives in Colorado, where she enjoys skiing, hiking, camping, and touring the geology of the West and the National Parks with her husband and two children.

Joshua Stevens NASA Pakistan Floods Satellite Images
Joshua Stevens

Since 2015, Joshua Stevens has been the lead visualizer of the NASA Earth Observatory. He has researched and taught cartographic design, geovisual analytics, and remote sensing for more than a decade. He was the lead author of the 2012 update to the online geography textbook, Mapping Our Changing World. His work has been featured by a variety of media, including The New York Times, The Washington Post, National Geographic, and the Discovery Channel.

Joshua was an NSF IGERT Fellow in big data social science at The Pennsylvania State University, where he pursued a Ph.D. in geography. He also earned a master’s in geography and a bachelor’s degree in geographic information science at Michigan State University. Joshua is a member of the North American Cartographic Information Society, and he enjoys geocaching, photography, and spending time with his wife and two children.
